Support Channels

Field of application

• Ideal for pipe installation as support structure for air ducts
• Variety of mounting options for pre-wall installations and shelves in combination with extensive range of system components

Advantages

• Quick and efficient attachment of pipe sections and multiple pipe-ways
• Scale marks on the sides and on the side with the slot simplify the alignment of the attachment elements during installation and facilitate the measuring and cutting to length of the section on site
• For secure fixing that is adjustable laterally and vertically
• High bending stiffness due to the cross-section design
• For setting up structured with correctly measured static loads by means of diverse connection components
• Suitable vibration control elements for all support channels available
• Clean-cut appearance by the use of protection caps

Product properties

Profile	Length(mm)	Part no.	Sales Unit	Pack Unit
27/18	1,000	129883	25	Pieces
	2,000	129911
	6,000	130003	1
28/30	2,000	118590	8
	3,040	118692	1
	4,000	118822	8
	6,000	118994	1
38/24	2,000	139920	10
	6,000	139922	1
